SM2YER Goran's Homepage

- Working conditions -

- 160 Meter / 1.8-2.0 MHz -

Tranceiver1 ........ ICOM IC-756proIII
Tranceiver2 ........ YAESU FT-847 (Spare)
Amplifier .......... KENWOOD TL-922
Antenna ............ Super Linear-Loaded Inverted V
                     SWR @ MHz
                     Using 'RadioWorks B1.2K+' 1:1 Current Balun

- 80 Meter / 3.5-2.8 MHz -

Tranceiver1 ........ ICOM IC-756proIII
Tranceiver2 ........ YAESU FT-847 (Spare)
Tranceiver3 ........ DRAKE TR-4C
Amplifier .......... KENWOOD TL-922
Antenna1 ........... HF2V
                     SWR 1:1,5 @ 3,713 MHz
Antenna2 ........... Dipole 2 x 18,46 meter
                     SWR 1:1 @ 3730KHz
                     Using 'RadioWorks B1.2K+' 1:1 Current Balun


Testresult with miniVNA

- 40 Meter / 7.0-7.1 MHz -

Tranceiver1 ........ ICOM IC-756proIII
Tranceiver2 ........ YAESU FT-847 (Spare)
Tranceiver3 ........ DRAKE TR-4C
Amplifier .......... KENWOOD TL-922
Antenna ............ HF2V
                     SWR 1:1,2 @ 7,038 MHz

- 20 Meter / 14.0-14.35 MHz -

Tranceiver1 ........ ICOM IC-756proIII
Tranceiver2 ........ YAESU FT-847 (Spare)
Tranceiver3 ........ DRAKE TR-4C
Amplifier .......... KENWOOD TL-922
Antenna ............ HY-GAIN TH-7 DX
                     SWR 1:1,1 @ 14,200MHz


Testresult with miniVNA

- 17 Meter / 18.068-18.168 MHz - (WARC)

Tranceiver1 ........ ICOM IC-756proIII
Tranceiver2 ........ YAESU FT-847 (Spare)
Amplifier .......... N/A
Antenna ............ 7el. Dualband 12/17 Meter Yagi

- 15 Meter / 21.0-21.45 MHz -

Tranceiver1 ........ ICOM IC-756proIII
Tranceiver2 ........ YAESU FT-847 (Spare)
Tranceiver3 ........ DRAKE TR-4C
Amplifier .......... KENWOOD TL-922
Antenna ............ HY-GAIN TH-7 DX
                     SWR 1:1,05 @ 21,220MHz


Testresult with miniVNA

- 12 Meter / 24.890-24.990 MHz - (WARC)

Tranceiver1 ........ ICOM IC-756proIII
Tranceiver2 ........ YAESU FT-847 (Spare)
Amplifier .......... N/A
Antenna ............ 7el. Dualband 12/17 Meter Yagi

- 10 Meter / 28.0-29.7 MHz -

Tranceiver1 ........ ICOM IC-756proIII
Tranceiver2 ........ YAESU FT-847 (Spare)
Tranceiver3 ........ DRAKE TR-4C
Amplifier .......... KENWOOD TL-922
Antenna ............ HY-GAIN TH-7 DX
                     SWR 1:1,2 @ 28,200


Testresult with miniVNA

- 6 Meter / 50.0-52.0 MHz -

Tranceiver1 ........ ICOM IC-756proIII
Tranceiver2 ........ YAESU FT-847 (Spare)
Amplifier .......... N/A
Antenna ............ N/A

- 2 Meter / 144.0-146.0 MHz -

Tranceiver ......... YAESU FT-847
Amplifier .......... N/A
Antenna ............ X-300 Dualband vertical
                     SWR 1:1 @ 145,400 MHz
                     SWR < 1:1,5 From 142,2 up to 148,6 MHz


Testresult with miniVNA

- 70CM / 432.0-434.0 MHz -

Tranceiver ......... YAESU FT-847
Amplifier .......... N/A
Antenna ............ X-300 Dualband vertical

SWR measured using Kuranishi BR-210 SWR-Analyser
